TZ Navigator Weather Routing Module - Digital Download

Navigate Safely & Efficiently
Like all sailors know, the most direct route isn't always the best one. The new Routing Module now combines its revolutionary algorithm allowing you to calculate the optimal sailing route based on weather forecasts, currents, polars of your yacht and your own navigation style, with the powerful features of the former Advanced Routing Module to make one product.

More performance in routing calculation
The new Routing module offers accuracy and flexibility for the most demanding sailing conditions making the software routing calculation easier. It allows advanced sailors to manually control and adjust the weather file parameters in order to get more accurate results. It also introduces the variability notion, helping the skipper to identify the particular moments in the navigation where strategy choices are critical.

Routing Module Features:
  • Waves are used for routing computation along with wind and currents
  • One click comparison between several routes and animations to evaluate multiple scenarios
  • Option to pass a waypoint, leaving it Port or Starboard during multi waypoint routing computation
  • Alternative Routing
  • Routing variability calculation and display
  • Weather File Adjustment
  • Its use is more intuitive and user-friendly for recreational boaters, while offering multiple setting options for experienced sailors


Routing variability calculation & display
After having created a routing you can display on chart the variability.Variability's value allows identifying quickly important variation of wind direction and strength which require from the skipper a supplementary expertise of his forecasts, routing and sourcing files.
  • The variability is equal to 100% if wind direction and strength are stable
  • It will decrease to 80% if the routing shows important variations of the wind direction and strength. It indicates as well the weather transition for example a ridge with a gradient decreasing of pressure thus of wind


Variability is symbolized in the Routing tree by a more or less strong display density (as it is shown in the picture above beside).

  • Areas colored in Black indicate weather transitions. A very dense black corresponds to a variability < 70 % and it is thus necessary to cross it in the shortest after an analysis more refined and recalculating a new routing before changing criteria as well as modifying parameters and files sources

  • Light areas show the "Corridors" where weather conditions are more stable depending to forecasts


The ability to overlay both together variability and Sailset allows you to clearly view each transition of different ways (as ridge) across the routing. The Variability value is indicated in each line of the Routing center which corresponds to a time period of the weather routing.

Weather File Adjustment
It is possible to adjust the wind forecast data values, in order, for example, to take into account the hours or wind direction or wind speed, which has been prevailing in the zone for several days.

  • Increase or decrease the wind speed (%): move the cursor along the slide bar to modify to increase or decrease the percentage
  • Increase or decrease the wind speed (value): enter directly a value
  • Change Weather File Time: enter a specific time HH:MM
  • Change Weather File in Latitude and Longitude
  • Change Weather File Direction
  • Increase or decrease in percentage Waves and/or Current values


American Sourced Marine Parts:


The product on this page ships worldwide from the United States by Fedex, UPS, Aramex or DHL.
These are premium services with tracking.  Delivery to most destinations is between 6-9 business days.
The minimum freight charge is AUD$85 (about US$57) See table below.


All prices shown are in Australian AUD$.

We sell this part by the manufacturer's part number.  These products are special order from the USA, meaning
there are no returns, no exchanges and no refunds possible.  The sale is final.


Prices include Australian 10% GST, but may be subject to further customs fees or charges if the order is over AUD$1000.
Shipments outside of Australia are tax free.


Any additional import fees are paid by the customer.  We will assist with customs formalities if necessary.


Manufacturer's warranty applies.  The warranty is in the box.  If a product is dead on arrival, we will replace it.
Where possible warranty DIY spare parts will be provided.
MarineDirect Australia will contribute $50 towards your return freight charges to the USA
within one year of order if there is a warranty issue.


Dangerous Goods:


Liquids, gels, pastes and replacement lithium batteries may not ship under any circumstances.


Grey Marketing & Compliance:


Where a brand has an established distributor in
Australia, we will decline to sell it.
Most such brands and products have been removed
from our American listings.
Some items shown within this category are intended only
for the American marketplace and
may not be compliant with Australian Standards
and in which case we cannot sell them to you and/or will refund you.




Express Freight Charges:  Total freight cost is based on the weigh of the package.


The default freight charge is $85 for the first kilo.


The shipping weight kg of the item is shown
under the Specifications tab above.


We use Fedex, UPS, DHL and Aramex Fedex which is generally a 6-9 business day service. Tracking is provided.


Following your purchase we will calculate the freight charges based on the table below.   The default shipping rate for 1kg for any order is $85.


If the weight is greater than 1 kilo, then the following additional amounts will be payable in arrears AUD$ and prior to shipping:





0-1kg $85 (This is the default rate)


>1-2kg  +$40


>2-3kg  +$65


>3-4kg  +$80


10kg    +$185


15kg    +$240


20kg    +$295


Some bulky items may be classified as oversize regardless of their weight.  Freight charges over 1 kilo will be based on the table above.
